XC0022C Explosion Proof by TECO-Westinghouse Motors

TECO-Westinghouse XC0022C 2 HP 230, 460V 3600 RPM 145TC TEFC-XP 3-Phase Motor

Name: TECO-Westinghouse XC0022C 2 HP 230, 460V 3600 RPM 145TC TEFC-XP 3-Phase Motor
Brand: TECO-Westinghouse
SKU: XC0022C
Price: 788.64 CAD
Availability: LimitedAvailability

Explosion Proof Motor

Brand: TECO-Westinghouse Motors

Category: Explosion Proof, Motors

$788.64

2HP

230, 460Voltage

3600RPM

145TCFrame

The TECO Westinghouse Explosion Proof XC0022C motor delivers legendary power and modern performance for demanding industrial, marine, and utility applications. Built with 3 phase, 2 HP, 230, 460 Voltage Rating, 3600 RPM Speed, 145TC Frame, C-Face / Rigid mounting, 5.0/2.5 Amps, F Insulation Class, Continuous Duty, TEFC-XP Enclosure Type, this motor ensures exceptional reliability, high torque output, and long operational life, even in the harshest environments. Featuring a 3, TEFC-XP, and C-Face / Rigid, the TECO Westinghouse motor is engineered for efficiency and endurance, utilizing Thermalastic® insulation systems that resist moisture, heat, and thermal stress.

Its robust AC and DC designs, coupled with precision-balanced rotors and heavy-duty bearings, make it ideal for continuous-duty applications such as pumps, compressors, conveyors, fans, and marine drives.

Each unit is built to meet or exceed NEMA and IEC standards, supporting both direct-on-line and inverter-duty systems. Whether used in steel mills, petrochemical facilities, mining operations, or power generation, the TECO Westinghouse Explosion Proof XC0022C motor delivers the durability, efficiency, and performance trusted by professionals worldwide.

Looking for expert help selecting the right TECO Westinghouse motor? Contact Electracore, your trusted Canadian TECO Westinghouse supplier, for genuine products, technical support, and fast nationwide shipping.

Authorized Canadian distributorExpert tech support (phone & email)30-day return policy

Brand	TECO-Westinghouse
General Category	Motors > Explosion Proof
Horsepower	2
Voltage	230, 460
RPM	3600
Amps	5.0/2.5
Frequency	60 Hz
Frame	145TC
Enclosure	TEFC-XP
Rotation	Reversible
Mounting	C-Face / Rigid
Phases	3
Motor Orientation	Horizontal
Number Of Poles	2
Duty Cycle	Continuous
Efficiency	85.5
Insulation Class	F
KVA Code	L
NEMA Design	B
Power Rating In Kw	1.5
Speeds	1 Speed
Power Factor	87
Service Factor	1.15
De Bearing Size	6205ZZ
Ode Bearing Size	6205ZZ
Frame Material	Cast Iron
Weight	31.746
Warranty	3-Year
Locked Rotor Current	50.00/25.00 AMP
Motor Fl Current	5.59 AMP
Leads	9
Connection	Wye
Variable Torque Ratio	20:01
Constant Torque Ratio	5:01
Connection Box Location	F1
Ambient Temp	-40 to 40 °C
Temp Code	T3B
Grease	Multemp SRL
Greasable	No
Temp Code Sine Wave Power	T3B
Dim Unit	cm
Length	88.9
Width	81.28
Height	50.8
Weight Unit	kg
Teco Datapack Link	/product-pdf/TECO-DATAPACK/tSbQdv9b-g8d-21-25.pdf
Teco Manual Link	/product-pdf/TECO-MANUALS/t9Tm7OMRj_ik-19-20.pdf
Teco Brochure Link	/product-pdf/TECO_BROCHURE/tyrSwERcD99u-25-6.pdf
Teco Features Link	/product-pdf/TECO-FEATURESHEET/t9Tm6AtSGn9F-17-29.pdf
Ref Product Title 1	xc0022-c
Product 1 Url	/product/xc0022-c
Ref Product Title 2	cx002402npw21x
Product 2 Url	/product/cx002402npw21x
Ref Product Title 3	cxm14222t
Product 3 Url	/product/cxm14222t
Product 4 Url	/product/
Teco Datapack	tSbQdv9b-g8d-21-25.pdf
Teco Manual	t9Tm7OMRj_ik-19-20.pdf
Teco Brochure	tyrSwERcD99u-25-6.pdf
Teco Features	t9Tm6AtSGn9F-17-29.pdf

Enter your email and we’ll confirm availability for this item before you place your order.

Product Info

Brand: TECO-Westinghouse

HP: 2

Voltage: 230, 460

RPM: 3600

Amperage: 5.0/2.5

Frame: 145TC

Enclosure: TEFC-XP

Phase: 3

Efficiency Rating: 85.5

Mounting Type: C-Face / Rigid

Insulation Class: F

Service Factor: 1.15

Duty Cycle: Continuous

Ambient Temperature Rating: -40 to 40 °C
