SDP01065 General Purpose by TECO-Westinghouse Motors

TECO-Westinghouse SDP01065 10 HP 575V 1200 RPM 256T ODP 3-Phase Motor

Name: TECO-Westinghouse SDP01065 10 HP 575V 1200 RPM 256T ODP 3-Phase Motor
Brand: TECO-Westinghouse
SKU: SDP01065
Price: 1373.61 CAD
Availability: InStock

General Purpose Motor

Brand: TECO-Westinghouse Motors

Category: General Purpose, Motors

$1,373.61

The TECO Westinghouse General Purpose SDP01065 motor delivers legendary power and modern performance for demanding industrial, marine, and utility applications. Built with 3 phase, 10 HP, 575 Voltage Rating, 1200 RPM Speed, 256T Frame, Rigid mounting, 10.1 Amps, F Insulation Class, Continuous Duty, ODP Enclosure Type, this motor ensures exceptional reliability, high torque output, and long operational life, even in the harshest environments. Featuring a 3, ODP, and Rigid, the TECO Westinghouse motor is engineered for efficiency and endurance, utilizing Thermalastic® insulation systems that resist moisture, heat, and thermal stress.

Its robust AC and DC designs, coupled with precision-balanced rotors and heavy-duty bearings, make it ideal for continuous-duty applications such as pumps, compressors, conveyors, fans, and marine drives.

Each unit is built to meet or exceed NEMA and IEC standards, supporting both direct-on-line and inverter-duty systems. Whether used in steel mills, petrochemical facilities, mining operations, or power generation, the TECO Westinghouse General Purpose SDP01065 motor delivers the durability, efficiency, and performance trusted by professionals worldwide.

Looking for expert help selecting the right TECO Westinghouse motor? Contact Electracore, your trusted Canadian TECO Westinghouse supplier, for genuine products, technical support, and fast nationwide shipping.

Free Canadian Shipping on orders 499+Authorized Canadian distributorExpert tech support (phone & email)30-day return policy

Total Sales	0
Brand	TECO-Westinghouse
General Category	Motors > General Purpose
Horsepower	10
Voltage	575
RPM	1200
Amps	10.1
Frequency	60 Hz
Frame	256T
Enclosure	ODP
Rotation	Reversible
Mounting	Rigid
Phases	3
Motor Orientation	Horizontal
Number Of Poles	6
Duty Cycle	Continuous
Efficiency	91.7
Insulation Class	F
IP Rating	IP22
KVA Code	H
NEMA Design	B
Power Rating In Kw	7.5
Speeds	1 Speed
Power Factor	81
Service Factor	1.15
De Bearing Size	6310ZZ
Ode Bearing Size	6309ZZ
Frame Material	Cast Iron
Weight	130.159
Warranty	3-Year
Locked Rotor Current	64.8 AMP
Leads	3
Connection	Delta
Variable Torque Ratio	20:01
Constant Torque Ratio	10:01
Connection Box Location	F1
Ambient Temp	-40 to 40 °C
Grease	Multemp SRL
Greasable	No
Dim Unit	cm
Length	66
Width	48
Height	33
Weight Unit	kg
Teco Datapack Link	/product-pdf/TECO-DATAPACK/tSbQdv9b-g8d-21-34.pdf
Teco Manual Link	/product-pdf/TECO-MANUALS/t9Tm7OMRj_ik-20-32.pdf
Teco Brochure Link	/product-pdf/TECO_BROCHURE/tyrSwERcD99u-6-77.pdf
Teco Features Link	/product-pdf/TECO-FEATURESHEET/t9Tm6AtSGn9F-29-8.pdf
Ref Product Title 1	mpop-33
Product 1 Url	/product/mpop-33
Ref Product Title 2	rd01065
Product 2 Url	/product/rd01065
Ref Product Title 3	d10p3g
Product 3 Url	/product/d10p3g
Ref Product Title 4	dp010506npw01
Product 4 Url	/product/dp010506npw01
Teco Datapack	tSbQdv9b-g8d-21-34.pdf
Teco Manual	t9Tm7OMRj_ik-20-32.pdf
Teco Brochure	tyrSwERcD99u-6-77.pdf
Teco Features	t9Tm6AtSGn9F-29-8.pdf

Enter your email and we’ll confirm availability for this item before you place your order.

Product Info

Brand: TECO-Westinghouse

HP: 10

Voltage: 575

RPM: 1200

Amperage: 10.1

Frame: 256T

Enclosure: ODP

Phase: 3

Efficiency Rating: 91.7

Mounting Type: Rigid

Insulation Class: F

Service Factor: 1.15

Duty Cycle: Continuous

Ambient Temperature Rating: -40 to 40 °C

TECO-Westinghouse, born from the heritage of Westinghouse and TECO innovation, delivers electric motors and power solutions from fractional duty to 100,000 HP.

Their products, power pumps, compressors, grinders, marine systems, and mining equipment, are used across various industries worldwide, built for rugged use in petrochemical, utility, steel, and marine environments.

As a trusted Canadian supplier and dealer, Electracore brings TECO-Westinghouse’s full line to your doorstep. We offer genuine products, expert support, and fast shipping to customers across Canada.
