RF0052 General Purpose by TECO-Westinghouse Motors

TECO-Westinghouse RF0052 5 HP 230, 460V 3600 RPM 184T TEFC 3-Phase Motor

Name: TECO-Westinghouse RF0052 5 HP 230, 460V 3600 RPM 184T TEFC 3-Phase Motor
Brand: TECO-Westinghouse
SKU: RF0052
Price: 493.83 CAD
Availability: InStock

General Purpose Motor

Brand: TECO-Westinghouse Motors

Category: General Purpose, Motors

$493.83

The TECO Westinghouse General Purpose RF0052 motor delivers legendary power and modern performance for demanding industrial, marine, and utility applications. Built with 3 phase, 5 HP, 230, 460 Voltage Rating, 3600 RPM Speed, 184T Frame, Rigid mounting, 11.6/5.8 Amps, F Insulation Class, Continuous Duty, TEFC Enclosure Type, this motor ensures exceptional reliability, high torque output, and long operational life, even in the harshest environments. Featuring a 3, TEFC, and Rigid, the TECO Westinghouse motor is engineered for efficiency and endurance, utilizing Thermalastic® insulation systems that resist moisture, heat, and thermal stress.

Its robust AC and DC designs, coupled with precision-balanced rotors and heavy-duty bearings, make it ideal for continuous-duty applications such as pumps, compressors, conveyors, fans, and marine drives.

Each unit is built to meet or exceed NEMA and IEC standards, supporting both direct-on-line and inverter-duty systems. Whether used in steel mills, petrochemical facilities, mining operations, or power generation, the TECO Westinghouse General Purpose RF0052 motor delivers the durability, efficiency, and performance trusted by professionals worldwide.

Looking for expert help selecting the right TECO Westinghouse motor? Contact Electracore, your trusted Canadian TECO Westinghouse supplier, for genuine products, technical support, and fast nationwide shipping.

Free Canadian Shipping on orders 499+Authorized Canadian distributorExpert tech support (phone & email)30-day return policy

Total Sales	0
Brand	TECO-Westinghouse
General Category	Motors > General Purpose
Horsepower	5
Voltage	230, 460
RPM	3600
Amps	11.6/5.8
Frequency	60 Hz
Frame	184T
Enclosure	TEFC
Rotation	Reversible
Mounting	Rigid
Phases	3
Motor Orientation	Horizontal
Number Of Poles	2
Duty Cycle	Continuous
Efficiency	89.5
Insulation Class	F
IP Rating	IP44
KVA Code	J
NEMA Design	B
Power Rating In Kw	3.75
Speeds	1 Speed
Power Factor	90
Service Factor	1.15
De Bearing Size	6206ZZ
Ode Bearing Size	6205ZZ
Frame Material	Rolled Steel
Weight	38.095
Warranty	3-Year
Locked Rotor Current	92.00/46.00 AMP
Motor Fl Current	12.9 AMP
Leads	9
Connection	Wye
Variable Torque Ratio	20:01
Constant Torque Ratio	10:01
Connection Box Location	F1
Ambient Temp	-40 to 40 °C
Grease	Multemp SRL
Greasable	No
Dim Unit	cm
Length	106.68
Width	88.9
Height	63.5
Weight Unit	kg
Teco Datapack Link	/product-pdf/TECO-DATAPACK/tSbQdv9b-g8d-22-5.pdf
Teco Manual Link	/product-pdf/TECO-MANUALS/t9Tm7OMRj_ik-19-5.pdf
Teco Brochure Link	/product-pdf/TECO_BROCHURE/tyrSwERcD99u-7-31.pdf
Teco Features Link	/product-pdf/TECO-FEATURESHEET/t9Tm6AtSGn9F-8-25.pdf
Ref Product Title 1	s5p1a
Product 1 Url	/product/s5p1a
Ref Product Title 2	gt1012a
Product 2 Url	/product/gt1012a
Ref Product Title 3	elp5p1d
Product 3 Url	/product/elp5p1d
Ref Product Title 4	ht005402npw01
Product 4 Url	/product/ht005402npw01
Teco Datapack	tSbQdv9b-g8d-22-5.pdf
Teco Manual	t9Tm7OMRj_ik-19-5.pdf
Teco Brochure	tyrSwERcD99u-7-31.pdf
Teco Features	t9Tm6AtSGn9F-8-25.pdf

Enter your email and we’ll confirm availability for this item before you place your order.

Product Info

Brand: TECO-Westinghouse

HP: 5

Voltage: 230, 460

RPM: 3600

Amperage: 11.6/5.8

Frame: 184T

Enclosure: TEFC

Phase: 3

Efficiency Rating: 89.5

Mounting Type: Rigid

Insulation Class: F

Service Factor: 1.15

Duty Cycle: Continuous

Ambient Temperature Rating: -40 to 40 °C

TECO-Westinghouse, born from the heritage of Westinghouse and TECO innovation, delivers electric motors and power solutions from fractional duty to 100,000 HP.

Their products, power pumps, compressors, grinders, marine systems, and mining equipment, are used across various industries worldwide, built for rugged use in petrochemical, utility, steel, and marine environments.

As a trusted Canadian supplier and dealer, Electracore brings TECO-Westinghouse’s full line to your doorstep. We offer genuine products, expert support, and fast shipping to customers across Canada.
