TECO-Westinghouse RD02045 20 HP 575V 1800 RPM 256T ODP 3-Phase Motor

Name: TECO-Westinghouse RD02045 20 HP 575V 1800 RPM 256T ODP 3-Phase Motor
Brand: TECO-Westinghouse
SKU: RD02045
Price: 1217.37 CAD
Availability: LimitedAvailability

General Purpose Motor

Brand: TECO-Westinghouse Motors

Category: General Purpose, Motors

$1,217.37

20HP

575Voltage

1800RPM

256TFrame

The TECO Westinghouse General Purpose RD02045 motor delivers legendary power and modern performance for demanding industrial, marine, and utility applications. Built with 3 phase, 20 HP, 575 Voltage Rating, 1800 RPM Speed, 256T Frame, Rigid mounting, 19.4 Amps, F Insulation Class, Continuous Duty, ODP Enclosure Type, this motor ensures exceptional reliability, high torque output, and long operational life, even in the harshest environments. Featuring a 3, ODP, and Rigid, the TECO Westinghouse motor is engineered for efficiency and endurance, utilizing Thermalastic® insulation systems that resist moisture, heat, and thermal stress.

Its robust AC and DC designs, coupled with precision-balanced rotors and heavy-duty bearings, make it ideal for continuous-duty applications such as pumps, compressors, conveyors, fans, and marine drives.

Each unit is built to meet or exceed NEMA and IEC standards, supporting both direct-on-line and inverter-duty systems. Whether used in steel mills, petrochemical facilities, mining operations, or power generation, the TECO Westinghouse General Purpose RD02045 motor delivers the durability, efficiency, and performance trusted by professionals worldwide.

Looking for expert help selecting the right TECO Westinghouse motor? Contact Electracore, your trusted Canadian TECO Westinghouse supplier, for genuine products, technical support, and fast nationwide shipping.

Authorized Canadian distributorExpert tech support (phone & email)30-day return policy

Brand	TECO-Westinghouse
General Category	Motors > General Purpose
Horsepower	20
Voltage	575
RPM	1800
Amps	19.4
Frequency	60 Hz
Frame	256T
Enclosure	ODP
Rotation	Reversible
Mounting	Rigid
Phases	3
Motor Orientation	Horizontal
Number Of Poles	4
Duty Cycle	Continuous
Efficiency	93
Insulation Class	F
IP Rating	IP22
KVA Code	G
NEMA Design	B
Power Rating In Kw	15
Speeds	1 Speed
Power Factor	83
Service Factor	1.15
De Bearing Size	6309ZZC3
Ode Bearing Size	6208ZZC3
Frame Material	Rolled Steel
Weight	106.122
Warranty	3-Year
Locked Rotor Current	116 AMP
Leads	3
Connection	Delta
Variable Torque Ratio	20:01
Constant Torque Ratio	10:01
Connection Box Location	F1
Ambient Temp	-40 to 40 °C
Grease	Multemp SRL
Greasable	No
Dim Unit	cm
Length	66
Width	48
Height	33
Weight Unit	kg
Teco Datapack Link	/product-pdf/TECO-DATAPACK/tSbQdv9b-g8d-19-2.pdf
Teco Manual Link	/product-pdf/TECO-MANUALS/t9Tm7OMRj_ik-1-20.pdf
Teco Brochure Link	/product-pdf/TECO_BROCHURE/tyrSwERcD99u-10-5.pdf
Teco Features Link	/product-pdf/TECO-FEATURESHEET/t9Tm6AtSGn9F-11-6.pdf
Ref Product Title 1	sdp02045
Product 1 Url	/product/sdp02045
Ref Product Title 2	d20p2g
Product 2 Url	/product/d20p2g
Ref Product Title 3	gt0162
Product 3 Url	/product/gt0162
Ref Product Title 4	dp020504npw01
Product 4 Url	/product/dp020504npw01
Teco Datapack	tSbQdv9b-g8d-19-2.pdf
Teco Manual	t9Tm7OMRj_ik-1-20.pdf
Teco Brochure	tyrSwERcD99u-10-5.pdf
Teco Features	t9Tm6AtSGn9F-11-6.pdf

Enter your email and we’ll confirm availability for this item before you place your order.

Product Info

Brand: TECO-Westinghouse

HP: 20

Voltage: 575

RPM: 1800

Amperage: 19.4

Frame: 256T

Enclosure: ODP

Phase: 3

Efficiency Rating: 93

Mounting Type: Rigid

Insulation Class: F

Service Factor: 1.15

Duty Cycle: Continuous

Ambient Temperature Rating: -40 to 40 °C

TECO-Westinghouse, born from the heritage of Westinghouse and TECO innovation, delivers electric motors and power solutions from fractional duty to 100,000 HP.

Their products, power pumps, compressors, grinders, marine systems, and mining equipment, are used across various industries worldwide, built for rugged use in petrochemical, utility, steel, and marine environments.

As a trusted Canadian supplier and dealer, Electracore brings TECO-Westinghouse’s full line to your doorstep. We offer genuine products, expert support, and fast shipping to customers across Canada.
