Full technical specifications appear below this section.
See the description below for full product details.
Typical applications include industrial machinery, HVAC systems, pumps, fans, conveyors, and general-purpose commercial equipment. Consult with our technical team for application-specific recommendations.
Contact us at [email protected] for datasheets, drawings, and technical documentation.
Our motor experts will help you pick the right unit for your application - no obligation.
Get Expert HelpEmail Us
| Brand | WORLDWIDE ELECTRIC |
|---|---|
| General Category | Motors > Definite Purpose > Close Coupled Pump Motors |
| Horsepower | 20 |
| Voltage | 230/460 |
| RPM | 3600 |
| Amps | 23.1 |
| Frequency | 60/50 |
| Frame | 256JP |
| Enclosure | TEFC |
| Mounting | C-Face with Feet |
| Efficiency | 91 |
| Insulation Class | Class F |
| IP Rating | IP55 |
| Service Factor | 1.15 |
| Weight | 297 |
| Url-datapack | x |
| Full Load Amps | 23.1 |
| Worldwide Datapack | t-shkLZaHabT-6-39.pdf |
| Worldwide Manual | t-shkLZaHabT-6-40.pdf |
Enter your email and we’ll confirm availability for this item before you place your order.
Matched products based on similar HP, RPM, Frame, Voltage, and Enclosure type.
HP: 20, RPM: 3600, Frame: 256JP, Voltage: 230, 460, Enclosure: TEFC
| HP | 20 |
| RPM | 3600 |
| VOLTAGE | 230, 460 |
| FRAME | 256JP |
| PHASE | 3 |
| ENCLOSURE | TEFC |
