Durable, cast iron construction – switch cap, motor and pump housing
Engineered plastic base
Stainless steel screws, bolts, handle, guard, arm and seal assembly
Corrosion-resistant, powder coated epoxy finish
Hermetically-sealed, automatic reset thermal overload protection
Upper and lower sleeve bearings running in bath of oil
Carbon and ceramic shaft seal
Passes 2” (50 mm) spherical solids
2” NPT discharge
On point: 12-1/2” (31.8 cm)
Off point: 4-1/2” (11.4 cm)
Simplex and duplex systems available
Automatic and non-automatic models available
Non-automatic for variable level systems
Models available packaged with piggyback variable level float switch
3 year limited warranty
Consult factory for special applications:Electrical alternators for duplex systems available with variable level float switches.
Minimum recommended basin size – simplex: 18” x 30” (45.7 x 76.2 cm), duplex: 30” x 36” (76.2 x 91.4 cm)
Standard automatic – 4/10 HP, 34.5 lbs.(15.6 kg)
High water alarms available
Mechanical alternators available for duplex systems
The approximate gallons pumped out per cycle for standard models are:Tank Diameter : Gallons / Liters Pumped18” (46 cm) simplex : 8 gallons / 36 liters24” (60 cm) simplex : 15 gallons / 68 liters30” (76 cm) duplex : 22 gallons / 100 liters36” (91 cm) duplex : 33 gallons / 150 liters48” (122 cm) duplex : 60 gallons / 273 liters
