FSP4026S Fan and Blower Motors by Century Motors

Century FSP4026S 1/4 HP 115V 1200 RPM OAO 1-Phase Motor

Name: Century FSP4026S 1/4 HP 115V 1200 RPM OAO 1-Phase Motor
Brand: Century
SKU: FSP4026S
Availability: LimitedAvailability

Fan and Blower Motors HVAC Motors

Brand: Century Motors

Category: HVAC Motors, Fan and Blower Motors

Our selection of Century Motors Fan and Blower Motors FSP4026S drives offers reliable variable speed control for Fan and Blower Motors applications. Select a drive rated for 1/4-rated motors, with a wide range of input and output voltage options.

They feature 1 phase, 1/4 HP, 115 Voltage Rating, 1200 RPM Speed, Resilient Rings mounting, 4.0 Amps, A Insulation Class, Air Over Duty, OAO Enclosure Type. As trusted Century Motors motor suppliers and dealers, we make it easy to find the right model for industrial, commercial, or HVAC use.

The Century Motors is perfect for fans, blowers, furnaces, and air conditioners, providing a reliable, direct replacement that ensures consistent airflow and long system life.

Need help selecting the right motor speed controller or finding a legacy replacement? Contact our motor experts today.

Authorized Canadian distributorExpert tech support (phone & email)30-day return policy

Brand	Century
General Category	AC Motors – NEMA
Product Category	HVAC/R Motors
Sub Category	Fan and Blower Motors
Horsepower	1/4
Voltage	115
RPM	1200
Amps	4.0
Frequency	60
Enclosure	OAO
Rotation	Counterclockwise Lead End
Mounting	Resilient Rings
Max Ambient	40°C
Phases	1
Motor Orientation	Horizontal
Motor Type	Permanent Split Capacitor
Number Of Poles	6
CSA Certified	N
CE Certified	N
Duty Cycle	Air Over
Insulation Class	A
Starting Type	Across The Line
Overload Protector	Automatic
Power Rating In Kw	0.19
Speeds	1
Service Factor	1
Speed2	1050
De Bearing Type	Sleeve
Ode Bearing Type	Sleeve
Dim Unit	IN
Length	13.18
Width	7.25
Height	7.37
Shaft Diameter	0.500
Shaft Extension	5.5
Shaft Type	Flat
C Dim	10.86
Frame Length	4.25
Frame Material	Rolled Steel
Weight Unit	LB
Weight	12.00
Url-datapack	https://cdnmedia.regalbeloit.com/images/d120001/medias/docus/4565/Article_FSP4026S_DataPack_9.pdf
Connection Drawing No	614131-231
Outline Drawing No	FSP4026S-S01
Ul	Recognized
Manufacturer	Regal Beloit
Part ID	FSP4026S
UPC	786674021687
Features	Furnace – Air Handler – Fan Coil Motor 5.6" Diameter – 48 Frame Permanent Split Capacitor (PSC); Capacitor Required: 5 Mfd-250 Volts (Supplied with Motor) Thermally Protected Open Air Over Class A Insulation, 40°C Ambient Sleeve Bearing 1/2" Diameter Shaft with FlatЅ" Leads Extended Studs Shaft End, Resilient Ring Mount, Belly Band Mount

Enter your email and we’ll confirm availability for this item before you place your order.

Product Info

Furnace – Air Handler – Fan Coil Motor 5.6″ Diameter – 48 Frame Permanent Split Capacitor (PSC); Capacitor Required: 5 Mfd-250 Volts (Supplied with Motor) Thermally Protected Open Air Over Class A Insulation, 40°C Ambient Sleeve Bearing 1/2″ Diameter Shaft with FlatЅ” Leads Extended Studs Shaft End, Resilient Ring Mount, Belly Band Mount

Brand: Century

HP: 1/4

Voltage: 115

RPM: 1200

Amperage: 4.0

Frame: 48Y

Enclosure: OAO

Phase: 1

-

Mounting Type: Resilient Rings

Insulation Class: A

Service Factor: 1

Duty Cycle: Air Over

-
