Our selection of Century Motors Fan and Blower Motors FSP4016S drives offers reliable variable speed control for Fan and Blower Motors applications. Select a drive rated for 1/5-rated motors, with a wide range of input and output voltage options.
They feature 1 phase, 1/5 HP, 115 Voltage Rating, 1200 RPM Speed, Resilient Rings mounting, 3.2 Amps, A Insulation Class, Air Over Duty, OAO Enclosure Type. As trusted Century Motors motor suppliers and dealers, we make it easy to find the right model for industrial, commercial, or HVAC use.
The Century Motors is perfect for fans, blowers, furnaces, and air conditioners, providing a reliable, direct replacement that ensures consistent airflow and long system life.
Need help selecting the right motor speed controller or finding a legacy replacement? Contact our motor experts today.
| Total Sales | 0 |
|---|---|
| Brand | Century |
| General Category | AC Motors – NEMA |
| Product Category | HVAC/R Motors |
| Sub Category | Fan and Blower Motors |
| Horsepower | 1/5 |
| Voltage | 115 |
| RPM | 1200 |
| Amps | 3.2 |
| Frequency | 60 |
| Enclosure | OAO |
| Rotation | Counterclockwise Lead End |
| Mounting | Resilient Rings |
| Max Ambient | 40°C |
| Phases | 1 |
| Motor Orientation | Horizontal |
| Motor Type | Permanent Split Capacitor |
| Number Of Poles | 6 |
| CSA Certified | N |
| CE Certified | N |
| Duty Cycle | Air Over |
| Insulation Class | A |
| Starting Type | Across The Line |
| Overload Protector | Automatic |
| Power Rating In Kw | 0.15 |
| Speeds | 1 |
| Service Factor | 1 |
| Speed2 | 1050 |
| De Bearing Type | Sleeve |
| Ode Bearing Type | Sleeve |
| Dim Unit | IN |
| Length | 13.18 |
| Width | 7.25 |
| Height | 7.37 |
| Shaft Diameter | 0.500 |
| Shaft Extension | 4.8 |
| Shaft Type | Flat |
| C Dim | 9.74 |
| Frame Length | 3.88 |
| Frame Material | Rolled Steel |
| Weight Unit | LB |
| Weight | 9.00 |
| Url-datapack | https://cdnmedia.regalbeloit.com/images/d120001/medias/docus/4563/Article_FSP4016S_DataPack_9.pdf |
| Connection Drawing No | 614131-231 |
| Outline Drawing No | FSP4016S-S01 |
| Ul | Recognized |
| Manufacturer | Regal Beloit |
| Part ID | FSP4016S |
| UPC | 786674021656 |
| Features | Furnace – Air Handler – Fan Coil Motor 5.6" Diameter – 48 Frame Permanent Split Capacitor (PSC); Capacitor Required: 5 Mfd-250 Volts (Supplied with Motor) Thermally Protected Open Shaft and Lead End End-Frame, Semi-Enclosed Shell, Air Over Class A Insulation, 40°C Ambient Sleeve Bearing 1/2" Diameter Shaft with FlatЅ" Leads Extended Studs Shaft End, Resilient Ring Mount, Belly Band Mount |
