APH0754 General Purpose by TECO-Westinghouse Motors

TECO-Westinghouse APH0754 75 HP 460V 1800 RPM 365T TEFC 3-Phase Motor

Name: TECO-Westinghouse APH0754 75 HP 460V 1800 RPM 365T TEFC 3-Phase Motor
Brand: TECO-Westinghouse
SKU: APH0754
Price: 7546.02 CAD
Availability: InStock

General Purpose Motor

Brand: TECO-Westinghouse Motors

Category: General Purpose, Motors

$7,546.02

The TECO Westinghouse General Purpose APH0754 motor delivers legendary power and modern performance for demanding industrial, marine, and utility applications. Built with 3 phase, 75 HP, 460 Voltage Rating, 1800 RPM Speed, 365T Frame, Rigid mounting, 85.1 Amps, F Insulation Class, Continuous Duty, TEFC Enclosure Type, this motor ensures exceptional reliability, high torque output, and long operational life, even in the harshest environments. Featuring a 3, TEFC, and Rigid, the TECO Westinghouse motor is engineered for efficiency and endurance, utilizing Thermalastic® insulation systems that resist moisture, heat, and thermal stress.

Its robust AC and DC designs, coupled with precision-balanced rotors and heavy-duty bearings, make it ideal for continuous-duty applications such as pumps, compressors, conveyors, fans, and marine drives.

Each unit is built to meet or exceed NEMA and IEC standards, supporting both direct-on-line and inverter-duty systems. Whether used in steel mills, petrochemical facilities, mining operations, or power generation, the TECO Westinghouse General Purpose APH0754 motor delivers the durability, efficiency, and performance trusted by professionals worldwide.

Looking for expert help selecting the right TECO Westinghouse motor? Contact Electracore, your trusted Canadian TECO Westinghouse supplier, for genuine products, technical support, and fast nationwide shipping.

Free Canadian Shipping on orders 499+Authorized Canadian distributorExpert tech support (phone & email)30-day return policy

Total Sales	0
Brand	TECO-Westinghouse
General Category	Motors > General Purpose
Horsepower	75
Voltage	460
RPM	1800
Amps	85.1
Frequency	60 Hz
Frame	365T
Enclosure	TEFC
Rotation	Reversible
Mounting	Rigid
Phases	3
Motor Orientation	Horizontal
Number Of Poles	4
CSA Certified	Class I, Div 2, Groups B, C & D
Duty Cycle	Continuous
Efficiency	95.4
Insulation Class	F
IP Rating	IP55
KVA Code	G
NEMA Design	B
Power Rating In Kw	55.95
Speeds	1 Speed
Power Factor	86.5
Service Factor	1.15
De Bearing Size	6313ZC3
Ode Bearing Size	6213ZC3
Shaft Diameter	2.375"
Shaft Extension	5.75"
C Dim	33.55"
Frame Material	Cast Iron
Weight	414.059
Warranty	3-Year
Locked Rotor Current	543 AMP
Leads	3
Connection	Delta
Variable Torque Ratio	20:01
Constant Torque Ratio	10:01
Connection Box Location	F1
Ambient Temp	-40 to 40 °C
Temp Code	T3C
Grease	Polyrex EM
Greasable	Yes
Temp Code Sine Wave Power	T3
Dim Unit	cm
Length	86
Width	66
Height	48
Weight Unit	kg
Teco Datapack Link	/product-pdf/TECO-DATAPACK/tSbQdv9b-g8d-51-18.pdf
Teco Manual Link	/product-pdf/TECO-MANUALS/t9Tm7OMRj_ik-39-17.pdf
Teco Brochure Link	/product-pdf/TECO_BROCHURE/tyrSwERcD99u-21-65.pdf
Teco Features Link	/product-pdf/TECO-FEATURESHEET/0
Ref Product Title 1	pdh0754
Product 1 Url	/product/pdh0754
Ref Product Title 2	ec0754
Product 2 Url	/product/ec0754
Ref Product Title 3	ht075404npw22
Product 3 Url	/product/ht075404npw22
Ref Product Title 4	em4316t
Product 4 Url	/product/em4316t
Teco Datapack	tSbQdv9b-g8d-51-18.pdf
Teco Manual	t9Tm7OMRj_ik-39-17.pdf
Teco Brochure	tyrSwERcD99u-21-65.pdf
Teco Features	0

Enter your email and we’ll confirm availability for this item before you place your order.

Product Info

Brand: TECO-Westinghouse

HP: 75

Voltage: 460

RPM: 1800

Amperage: 85.1

Frame: 365T

Enclosure: TEFC

Phase: 3

Efficiency Rating: 95.4

Mounting Type: Rigid

Insulation Class: F

Service Factor: 1.15

Duty Cycle: Continuous

Ambient Temperature Rating: -40 to 40 °C

TECO-Westinghouse, born from the heritage of Westinghouse and TECO innovation, delivers electric motors and power solutions from fractional duty to 100,000 HP.

Their products, power pumps, compressors, grinders, marine systems, and mining equipment, are used across various industries worldwide, built for rugged use in petrochemical, utility, steel, and marine environments.

As a trusted Canadian supplier and dealer, Electracore brings TECO-Westinghouse’s full line to your doorstep. We offer genuine products, expert support, and fast shipping to customers across Canada.
