APH04025 General Purpose by TECO-Westinghouse Motors

TECO-Westinghouse APH04025 40 HP 575V 3600 RPM 324TS TEFC 3-Phase Motor

Name: TECO-Westinghouse APH04025 40 HP 575V 3600 RPM 324TS TEFC 3-Phase Motor
Brand: TECO-Westinghouse
SKU: APH04025
Price: 3464.25 CAD
Availability: InStock

General Purpose Motor

Brand: TECO-Westinghouse Motors

Category: General Purpose, Motors

$3,464.25

The TECO Westinghouse General Purpose APH04025 motor delivers legendary power and modern performance for demanding industrial, marine, and utility applications. Built with 3 phase, 40 HP, 575 Voltage Rating, 3600 RPM Speed, 324TS Frame, Rigid mounting, 35.4 Amps, F Insulation Class, Continuous Duty, TEFC Enclosure Type, this motor ensures exceptional reliability, high torque output, and long operational life, even in the harshest environments. Featuring a 3, TEFC, and Rigid, the TECO Westinghouse motor is engineered for efficiency and endurance, utilizing Thermalastic® insulation systems that resist moisture, heat, and thermal stress.

Its robust AC and DC designs, coupled with precision-balanced rotors and heavy-duty bearings, make it ideal for continuous-duty applications such as pumps, compressors, conveyors, fans, and marine drives.

Each unit is built to meet or exceed NEMA and IEC standards, supporting both direct-on-line and inverter-duty systems. Whether used in steel mills, petrochemical facilities, mining operations, or power generation, the TECO Westinghouse General Purpose APH04025 motor delivers the durability, efficiency, and performance trusted by professionals worldwide.

Looking for expert help selecting the right TECO Westinghouse motor? Contact Electracore, your trusted Canadian TECO Westinghouse supplier, for genuine products, technical support, and fast nationwide shipping.

Free Canadian Shipping on orders 499+Authorized Canadian distributorExpert tech support (phone & email)30-day return policy

Total Sales	0
Brand	TECO-Westinghouse
General Category	Motors > General Purpose
Horsepower	40
Voltage	575
RPM	3600
Amps	35.4
Frequency	60 Hz
Frame	324TS
Enclosure	TEFC
Rotation	Reversible
Mounting	Rigid
Phases	3
Motor Orientation	Horizontal
Number Of Poles	2
CSA Certified	Class I, Div 2, Groups B, C & D
Duty Cycle	Continuous
Efficiency	94.1
Insulation Class	F
IP Rating	IP55
KVA Code	G
NEMA Design	B
Power Rating In Kw	29.84
Speeds	1 Speed
Power Factor	90
Service Factor	1.15
De Bearing Size	6312ZC3
Ode Bearing Size	6212ZC3
Shaft Diameter	1.875"
Shaft Extension	3.65"
C Dim	28.43"
Frame Material	Cast Iron
Weight	279.365
Warranty	3-Year
Locked Rotor Current	232 AMP
Leads	3
Connection	Delta
Variable Torque Ratio	20:01
Constant Torque Ratio	10:01
Connection Box Location	F1
Ambient Temp	-40 to 40 °C
Temp Code	T3C
Grease	Polyrex EM
Greasable	Yes
Temp Code Sine Wave Power	T3B
Dim Unit	cm
Length	76
Width	64
Height	41
Weight Unit	kg
Teco Datapack Link	/product-pdf/TECO-DATAPACK/tSbQdv9b-g8d-72-3.pdf
Teco Manual Link	/product-pdf/TECO-MANUALS/t9Tm7OMRj_ik-43-8.pdf
Teco Brochure Link	/product-pdf/TECO_BROCHURE/tyrSwERcD99u-40-1.pdf
Teco Features Link	/product-pdf/TECO-FEATURESHEET/0
Ref Product Title 1	gt1133a
Product 1 Url	/product/gt1133a
Ref Product Title 2	cd40p1gs
Product 2 Url	/product/cd40p1gs
Ref Product Title 3	ht040502npw22
Product 3 Url	/product/ht040502npw22
Ref Product Title 4	em4109t-5
Product 4 Url	/product/em4109t-5
Teco Datapack	tSbQdv9b-g8d-72-3.pdf
Teco Manual	t9Tm7OMRj_ik-43-8.pdf
Teco Brochure	tyrSwERcD99u-40-1.pdf
Teco Features	0

Enter your email and we’ll confirm availability for this item before you place your order.

Product Info

Brand: TECO-Westinghouse

HP: 40

Voltage: 575

RPM: 3600

Amperage: 35.4

Frame: 324TS

Enclosure: TEFC

Phase: 3

Efficiency Rating: 94.1

Mounting Type: Rigid

Insulation Class: F

Service Factor: 1.15

Duty Cycle: Continuous

Ambient Temperature Rating: -40 to 40 °C
