| Total Sales | 0 |
|---|---|
| Brand | US Motors |
| General Category | Motors > General Purpose |
| Horsepower | 75 |
| Voltage | 230 , 460 |
| RPM | 1800 |
| Amps | 172.0/86.0 |
| Frequency | 60 |
| Frame | 365T |
| Enclosure | ODP |
| Rotation | Reversible |
| Mounting | Rigid |
| Max Ambient | 40 °C |
| Phases | 3 |
| Assemblybox Mounting | F1 |
| Motor Orientation | Horizontal |
| Number Of Poles | 4 |
| Duty Cycle | Continuous |
| Efficiency | 95 |
| Insulation Class | F |
| KVA Code | F |
| NEMA Design | B |
| Power Rating In Kw | 55.93 |
| Speeds | 1 Speed |
| Service Factor | 1.15 |
| De Bearing Size | 6215-2Z-J |
| Ode Bearing Size | 6212-2Z-J |
| Shaft Diameter | 2.375" |
| Shaft Extension | 5.874" |
| C Dim | 29.7" |
| Frame Material | Cast Iron |
| Weight | 735lb |
| Pdf 1 Link | /product-pdfs/USM/ |
| Warranty | 1-Year |
| Full Load Temp | 80°C RISE/RES@FL 60HZ |
| Overview | General Purpose Three Phase ODP NEMA Premium Efficient – IE3 |
| Approvals | CSA & CE |
