285 Unit Bearing Motors by Century Motors

Century 285 230V 1800 RPM TEAO 1-Phase Motor

Name: Century 285 230V 1800 RPM TEAO 1-Phase Motor
Brand: Century
SKU: 285
Price: 250.15 CAD
Availability: InStock

Unit Bearing Motors HVAC Motors

Brand: Century Motors

Category: HVAC Motors, Unit Bearing Motors

$250.15

Our selection of Century Motors Unit Bearing Motors 285 drives offers reliable variable speed control for Unit Bearing Motors applications. Select a drive rated for -rated motors, with a wide range of input and output voltage options.

They feature 1 phase, 230 Voltage Rating, 1800 RPM Speed, 2 BOSS/OSE 3 HOLES mounting, 0.85 Amps, A Insulation Class, Continuous Duty, TEAO Enclosure Type. As trusted Century Motors motor suppliers and dealers, we make it easy to find the right model for industrial, commercial, or HVAC use.

The Century Motors is perfect for fans, blowers, furnaces, and air conditioners, providing a reliable, direct replacement that ensures consistent airflow and long system life.

Need help selecting the right motor speed controller or finding a legacy replacement? Contact our motor experts today.

Free Canadian Shipping on orders 499+Authorized Canadian distributorExpert tech support (phone & email)30-day return policy

Total Sales	0
Brand	Century
General Category	AC Motors – NEMA
Product Category	HVAC/R Motors
Sub Category	Unit Bearing Motors
Voltage	230
RPM	1800
Amps	0.85
Frequency	60
Enclosure	TEAO
Rotation	Clockwise Lead End
Mounting	2 BOSS/OSE 3 HOLES
Max Ambient	40°C
Phases	1
Motor Type	Shaded Pole
Number Of Poles	4
CSA Certified	Y
CE Certified	N
Duty Cycle	Continuous
Insulation Class	A
Starting Type	Across The Line
Overload Protector	Thermally Protected
Speeds	1
Service Factor	1
Speed2	1500
De Bearing Type	Unit
Ode Bearing Type	Unit
Dim Unit	IN
Length	9.41
Width	6.87
Height	6.87
Shaft Diameter	0.312
Shaft Extension	1.5
Shaft Type	Flat
Frame Length	4.91
Frame Material	Cast Iron
Weight Unit	LB
Weight	7.00
Url-datapack	https://cdnmedia.regalbeloit.com/images/d120001/medias/docus/4964/Article_285_DataPack_9.pdf
Outline Drawing No	285-S01
Ul	Recognized
Manufacturer	Regal Beloit
Part ID	285
UPC	786674006332
Supersedes	N/A
Features	OEM Direct Replacement Motor Unit Bearing Shaded PoleShaded Pole Thermally Protected Totally Enclosed Air Over Class A Insulation, 40°C Ambient Bearing – Unit 5/16" Diameter Shaft with FlatϾ" Leads Tapped Double Boss, 3 Tapped Holes Opposite Shaft End

Enter your email and we’ll confirm availability for this item before you place your order.

Product Info

OEM Direct Replacement Motor Unit Bearing Shaded PoleShaded Pole Thermally Protected Totally Enclosed Air Over Class A Insulation, 40°C Ambient Bearing – Unit 5/16″ Diameter Shaft with FlatϾ” Leads Tapped Double Boss, 3 Tapped Holes Opposite Shaft End

Brand: Century

HP: NA

Voltage: 230

RPM: 1800

Amperage: 0.85

Frame: UNIT BEARING

Enclosure: TEAO

Phase: 1

-

Mounting Type: 2 BOSS/OSE 3 HOLES

Insulation Class: A

Service Factor: 1

Duty Cycle: Continuous

-

Century Motors Motors For over 100 years, Century® has led the electric motor industry with breakthrough solutions across heating, ventilation, air conditioning (HVAC), recreational water, and industrial sectors. As a trusted partner to global clients, Century delivers high-performance, energy-efficient, and durable motor systems designed to meet evolving demand in commercial, industrial, residential, and recreational applications.

Whether your project requires an HVAC blower, pool pump motor, or heavy-duty industrial drive, Century continues to push boundaries, providing trusted, future-ready solutions for modern systems.
